Spout Pouch Filling and Capping Machine

Spout pouch filling and capping machine is suitable for 100ml -5000ml liquid or semi liquid pouch filling and capping. Used for packaging fruit juices, edible oils, seasonings, sauces, laundry detergent, etc. Detergent, etc. Widely used in the food and beverage, daily chemical, and pharmaceutical industries。

Spout Pouch Filling and Capping Machine

The spout pouch filling and capping machine is an industrial equipment used in the packaging industry for filling and sealing stand up pouch. The main function is to automatically fill the  pouch with liquid, seal it, and cover or nozzle the process. Fully automated production includes automatic bagging, fixed point filling, capping, insertion, capping, and finished product discharge. Suitable for various liquids and viscous products such as sauces, detergents, cosmetics, oils, paste, cream,etc.

spout pouch filling and capping machine
spout pouch filling and capping machine

Spout Pouch Filling and Capping Machine Features

1. PLC control using a touch screen human-machine interface system. The servo motor drives the double ball screw to lift and control the movement of the piston rod, ensuring the stability of filling and higher filling accuracy.
2. According to customer packaging materials and product requirements, pouch filling machine supports different sealing methods such as heat sealing, ultrasonic sealing, or induction sealing.
3. Support 2/4/6/8 filling heads, and customize the configuration of filling heads according to customer production volume
4. pouch filling and sealing machine is made of 304/316 grade stainless steel material, which is clean and hygienic, and meets GMP standards
5. The pouch fill seal machine is equipped with an automatically adjustable bottle cap processing and tightening device to ensure that the bottle cap is securely tightened.
6. The high-quality and commonly used components are all selected from well-known international companies, and the machine performance is stable.
7. liquid pouch filling and sealing machine can also be equipped with inkjet or bag labeling machine for date and batch coding on bags.

Spout Pouch Filling and Capping Machine Workflow

Pouch Loading – Pouch Detecting- Filling- SpoutCleaning- Cap Loading- Cap Detecting – Capping -Product Discharge

FAQs about automatic spout pouch filling and capping machine

The following are some common questions (FAQs) about automatic spout pouch filling machine:
1.What factors should be considered when selecting a pouch filling capping machine?
Mainly considering production capacity, product type of packaging, bag size and shape. In addition, the nozzle and cover types should also be evaluated.
2.Can the spouted pouch filling machine handle bags of different sizes?
Many spouted pouch filling machine can be adjusted to adapt to different bag sizes and shapes.
3. Can the pouch liquid filling machine be integrated into the existing production line?
Yes, pouch liquid filling machine can usually be integrated into existing packaging production lines.
Can stand up bags, flat bags,squeeze pouch, premade pouch and shaped bag filling machines fill?
Yes, the machine can handle different bag types, including vertical bags, flat bags, and various unique shaped bags.

Npack is a professional pouch filling and packing machinefactory. If you are interested, please contact us





Product Detail

spout pouch filling and capping machine sample bag

Filling Accuracy: ±0.1-0.5%

Filling volume:100ml-5oooml(Customized according to customer needs)

Pouch Type:stand up pouch with nozzle

Packaging Type: Wooden Case

After Warranty Service:Video technical support

Applicable Industries:Food ;Pharmaceutical;Chemical;Cosmetic

Filling Materials:juice, jam, oil,sauce, detergent,etc.





Nozzles Injector 2
Packing Speed 800-1500 bags/Hour
Volume 100-500ml
Powder 1.2kw
Voltage 380V/50HZ (three phase four line )
Air Pressure

0.5 – 0.7Mpa

Air consumption 0.65 m3/min
Out dimension Main Machine: 1700*1100*2000mm
Weight 600kg


This is spout pouch filling and capping machine video:
