NP-RL Vertical Round Bottle Labeling Machine
it is a sticker labeling machine for application one or two labels for round containers.
NP-RL Vertical round bottle Wrapping Labeling Machine
Round bottle Wrapping Labeling Machine
- This machine features a straightforward design and is user-friendly, ensuring high precision and reliability in label application.
- It is equipped with a sophisticated PLC control system that ensures consistent performance at high speeds, guaranteeing stable operation.
- The addition of a touch screen not only improves the machine’s usability by making information easy to read but also enhances its aesthetic appeal.
- With the capability to store over 10 sets of labeling parameters, it allows for quick and easy adjustments, streamlining the setup process for different products.
- Integrated automatic photoelectric detection functions enable the machine to identify the absence of objects, thereby canceling the labeling process to avoid mislabeling. It also pauses operation or activates an alarm when labels run out, minimizing label waste and ensuring no label is missed.
- The touch screen interface is designed to be user-friendly, supporting multiple languages such as English, Spanish, French, and Russian. This multilingual capability makes it easy for operators to use and ensures seamless integration into diverse production lines, enhancing operational efficiency across various packaging processes
Additionally, the machine boasts a state-of-the-art control system, powered by a servo motor PLC, which ensures seamless and efficient labeling operations. An intuitive human-machine interface, supporting both English and Chinese languages, further enhances its accessibility and ease of use. This integration of cutting-edge technology and user-centric design makes the NP-RL Vertical Round Bottle Wrapping Labeling Machine an essential tool for businesses aiming to optimize their labeling processes with precision, speed, and reliability.
- Operating Speed: 10–300 pcs/min
- Supported Bottle Sizes: Diameter 40–150mm,Height 10–300mm
- Compatible Label Size: Length 20–450mm, Width 10–100mm
Designed for left edge first, outside wound, non-perforated label stock (3in core) - Conveyor Height: 800–850mm
- Power Supply: AC110V, 50/60Hz, single phase
- Air Supply: 0.5–0.8MPa, 10L/min
- Working Environment: 10~40℃
- Surrounding Humidity: 15–85%
- Machine Dimensions: 2000mm (L) × 1100mm (W) × 1300mm (H)
- Machine Weight: 180kg
These parameters ensure reliable performance across a wide range of production environments and bottle types, offering flexibility and precision for your bottling and labeling needs.
Flexible Labeling for Diverse Bottle Sizes
The NP-RL Vertical Round Bottle Wrapping Labeling Machine is engineered for versatility, allowing you to label between 10 to 30 products per minute—making it an efficient upgrade from manual application. The machine handles a wide range of label sizes (20–450mm long, 10–100mm wide) and accommodates bottles with diameters from 20–150mm and heights of 10–300mm. Adjusting for various bottle dimensions is straightforward: simply use the convenient hand cranks for mechanical changes, while the intuitive touch screen interface lets you fine-tune product spacing, conveyor speed, and label position for optimal placement.
Once your settings are configured, loading products onto the conveyor is effortless. The labeling sensor detects each item, ensuring each bottle receives a perfectly applied label as it exits the system. This automated process not only eliminates the inconsistencies of hand labeling but also significantly boosts throughput and consistency across shifts.
Precision Engineering and Safety
The round bottle labeling machine is designed with exceptional precision and built to last, featuring a comprehensive assembly that includes a product transmission system, label dispensing unit, wrapping unit, a programmable logic control (PLC) panel, electric panel, and other advanced functionalities tailored to boost manufacturing efficiency and effectiveness. Safety has been a paramount consideration in its design, with all moving parts fully enclosed to mitigate risks.
The machine’s conveying system can be finely adjusted to cater to the unique requirements of different products, supported by a strong AC variable drive that provides the necessary torque for smooth operations. An innovative motorized system guarantees even spacing between products, ensuring consistent labeling. High-quality components from trusted suppliers are used in its construction, enhancing the machine’s durability and reducing the need for frequent maintenance. This machine represents a blend of safety, efficiency, and reliability, making it an essential addition to production lines requiring precise and durable labeling solutions
